Nano

---

The Cerakure Nano is a catalytic infrared curing oven built specifically for Cerakote applicators.
It cures coatings directly — not the air, not the part — reducing cure times from hours to minutes with dramatically less energy.

This is not a faster convection oven.
It’s a different process entirely.

Traditional convection ovens heat air, then heat the part, and eventually cure the coating.

The Nano does none of that.

Using catalytic infrared energy, the Nano targets the coating itself — exciting it directly in the optimal wavelength range. The result is a full cure in a fraction of the time, without overheating the substrate.

Typical comparison:

• Convection oven: ~2 hours @ 250°F

• Cerakure Nano: ~20 minutes


Once you experience it, waiting two hours feels unnecessary.

Speed doesn’t require brute force.

The Nano operates on:

• 120V / 2A

• ~6,000 BTU

• Standard electrical outlet

• Standard gas bottle


Because energy is delivered directly to the coating, there’s very little waste. You’re not heating an oven full of air — you’re curing parts efficiently and intentionally.

The Nano is designed to be as difficult to mess up as possible.

Every unit includes a dedicated wireless tablet that allows you to control the oven from anywhere in your shop.

Built-in features include:

• Pre-loaded Cerakote recipes

• Pre-loaded cure times

• Automatic start sequences

• Automatic hold functions

• No tuning, calibration, or guessing


You press Start.
The oven handles the rest.

Even if someone else runs it, the results stay consistent.

The Nano operates on a local wireless system, allowing full control without standing in front of the oven.

• Monitor and control from anywhere in the shop

• No cables

• No network configuration

• No subscriptions


Simple, reliable, and purpose-built for real shops.

The Nano was built specifically for:

• Cerakote applicators

• Firearms and small-parts shops

• High-mix, small-batch workflows


It is not intended for:

• Wood finishing

• Large panels

• Conveyor or production-line curing


For larger production needs, Cerakure offers larger systems through authorized distributors.

• Exterior dimensions: 24” W × 22” D × 32” T

• Usable interior space: 22” W × 20” D × 22” T

• Catalytic element: 8”

• Exhaust: 4”


Compact enough for a bench-scale workflow. Powerful enough to change how you schedule your day.

• Cerakure Nano catalytic IR oven

• Wireless control tablet

• Gas hose with regulator and bottle connector

• Pre-configured and ready to run


No assembly. No sourcing parts. No setup frustration.

• Faster turnaround

• Less energy consumption

• No bake queues

• No overnight waits

• More predictable scheduling


When curing takes 20 minutes instead of two hours, the entire workflow changes.
